At a glance
- Configuration
- Horizontal open skid
- Cooling
- Air-cooled
- Voltage / Frequency
- 380 V / 3-phase / 50 Hz (standard)
Model range
StationPack SN-H1 is one configuration within the StationPack SN open-skid family. Contact SIND for the current coverage.
Configuration
Horizontal open skid
- Configuration
- Horizontal open skid
Installation
Installation
- Plant rooms with height restriction, under mezzanine or low ceiling
How To Choose
By installation envelope
- START WITH
- Required flow and pressure
- THEN CHECK
- Height restriction and access
- BEFORE A QUOTE
- Confirm the model row with SIND
Technology
Technology Platform
StationPack SN-H1 uses the same core technology as the StationPack SN open-skid station family: oil-injected rotary screw compression, integrated drive, aftercooler, separator and drain, storage volume, optional drying and filtration, station sequencer and common control, all factory-piped and tested on one open baseframe. The horizontal configuration arranges these components in a low-profile layout for installations where vertical envelope is constrained.
Why Horizontal Configuration?
Horizontal layout addresses three installation constraints:
Key Design Decision: Open Skid
StationPack SN-H1 is an open skid, not an enclosed station. Open skid applies where the installation environment is sheltered: a plant room with existing ventilation, access and weather protection. Where the station sits outdoors, in a noisy bay, or in a dusty or salty environment, the enclosed StationPack SE series is the correct choice.
More technical detail
Why Horizontal Configuration?
- Height restriction — where the station must fit under a mezzanine, low ceiling or existing pipework, horizontal arrangement reduces the vertical envelope.
- Access and maintenance — horizontal layout places all service points at working height, reducing the need for ladders or overhead access.
- Transport and rigging — lower center of gravity simplifies transport, positioning and anchoring.
Integration and Control
The station arrives as one item with one set of test records. One control system sequences the machines and holds one narrow pressure band at the header, instead of each machine hunting on its own switch. The treatment train is sized against what the compressor delivers at the site’s pressure and ambient, not against a nameplate peak flow.
Selection & quote checklist
- Height restriction — Low ceiling or mezzanine above
- Sheltered environment — Plant room with ventilation and access
- Maintenance access — All service points at working height
- the exact model and configuration
- required operating pressure and flow
- electrical supply (voltage, frequency, phase)
Applications
Workshop with Low Ceiling
An existing workshop with a low ceiling requires additional compressed air capacity. Vertical envelope is constrained by existing structure.
Mezzanine Installation
A manufacturing facility has installed a mezzanine for additional work space. The compressor station must be positioned below the mezzanine, where vertical clearance is limited.
Retrofit and Expansion
An existing plant room has height restriction from overhead pipework and structure. Adding capacity requires a station that fits within the available envelope.
Ownership & service
Energy, maintenance and service
Target Industries and Markets
StationPack SN-H1 is specified where an integrated compressor station is required but vertical envelope is constrained:
- Workshops with low ceilings — existing buildings where the compressor must fit under existing structure.
- Mezzanine installations — where the station sits below elevated work platforms.
- Retrofit and expansion — adding capacity to existing plant rooms with height constraints.
- Indoor installations — where weather protection exists but floor space is available.
How This Compares with Site-Assembled Stations
The point of StationPack is the boundary. Everything a buyer would otherwise assemble on site arrives as one item with one set of test records. One control system sequences the machines and holds one narrow pressure band at the header. The treatment train is sized against what the compressor delivers at the site’s pressure and ambient, not against a nameplate peak flow. Site-assembled stations carry the risk of mismatched components, multiple vendors and no single-point responsibility.
Specifications vary by configuration; confirm with the datasheet. Dimensions and weights are indicative; request the installation drawing for the specific model before designing foundations or access routes.
Reference data
Full specification and reference tables
- Height restriction — Low ceiling or mezzanine above
- Sheltered environment — Plant room with ventilation and access
- Maintenance access — All service points at working height
- the exact model and configuration
- required operating pressure and flow
- electrical supply (voltage, frequency, phase)
- the current datasheet and package contents
-
SN-H1 or SN-V (vertical)?
SN-H1 horizontal for height restriction, mezzanine or low ceiling. SN-V vertical where vertical envelope is available and floor footprint must be minimised.
-
SN-H1 or SE (enclosed)?
SN-H1 open skid for a sheltered plant room with existing ventilation and access. SE enclosed for outdoor, noisy or dusty environments.
-
What is inside?
Compressor, drive, cooling, aftercooler, separator and drain, storage volume, optional drying and filtration, control and protection, open baseframe, internal pipework and wiring. Exact scope is confirmed per order.
-
Installation?
Foundations, power, cooling air, header and condensate connections. Drawings are available on request.
-
Is 60 Hz available?
50 Hz standard. 60 Hz configuration on request — confirm voltage, frequency and phase with your SIND representative before order.
